Super Smash Bros. Brawl

A work-in-progress slopcoded decompilation of Super Smash Bros. Brawl.

This repository does not contain any game assets or assembly whatsoever. An existing copy of the game is required.

Supported versions:

• RSBE01_02: USA Rev 2

Dependencies

Windows

On Windows, it's highly recommended to use native tooling. WSL or msys2 are not required.
When running under WSL, objdiff is unable to get filesystem notifications for automatic rebuilds.

• Install Python and add it to %PATH%.
  • Also available from the Windows Store.
• Download ninja and add it to %PATH%.
  • Quick install via pip: pip install ninja

macOS

• Install ninja:

  brew install ninja

• Install wine-crossover:

  brew install --cask --no-quarantine gcenx/wine/wine-crossover

After OS upgrades, if macOS complains about Wine Crossover.app being unverified, you can unquarantine it using:

sudo xattr -rd com.apple.quarantine '/Applications/Wine Crossover.app'

Linux

• Install ninja.
• For non-x86(_64) platforms: Install wine from your package manager.
  • For x86(_64), wibo, a minimal 32-bit Windows binary wrapper, will be automatically downloaded and used.

Building

• Clone the repository:

  git clone https://github.com/doldecomp/brawl.git

• Update and Initialize submodules:

  git submodule update --init --recursive

• Copy your game's disc image to orig/RSBE01_02 (or the appropriate version).

  • Supported formats: ISO (GCM), RVZ, WIA, WBFS, CISO, NFS, GCZ, TGC
  • After the initial build, the disc image can be deleted to save space.

• Configure:

  python configure.py

  To use a version other than RSBE01_02 (USA Rev 2), specify it with --version.

• Build:

  ninja

Diffing

Once the initial build succeeds, an objdiff.json should exist in the project root.

Download the latest release from encounter/objdiff. Under project settings, set Project directory. The configuration should be loaded automatically.

Select an object from the left sidebar to begin diffing. Changes to the project will rebuild automatically: changes to source files, headers, configure.py, splits.txt or symbols.txt.

Contributors and AI agents

See AGENTS.md for the full agent instructions.

Much of the work in this fork is done by AI agents (Claude, Codex) working for a person. Commits should show who ran the agent and which agent it was:

• Author and committer = the human whose account or credits run the agent (for example Brendan, GitHub brendan-hoenn, or May, GitHub may-petalburg). Use that person's GitHub noreply address (<id>+<username>@users.noreply.github.com, for example 4410221+brendan-hoenn@users.noreply.github.com).
• Co-author = the agent, as one trailer at the end of the message, with your model name if you know it, so GitHub shows "Human and Agent":
  • Co-Authored-By: Claude <model name> <noreply@anthropic.com> (for example Co-Authored-By: Claude Sonnet 5.5 <noreply@anthropic.com>)
  • Co-Authored-By: Codex <model name> <267193182+codex@users.noreply.github.com> (for example Co-Authored-By: Codex GPT-6.1 Sol <267193182+codex@users.noreply.github.com>; use the exact model name your environment reports, never a guess)
  • If you do not know your model name, leave it out (Claude / Codex alone).
• Never commit as just Claude or codex, never leave session links in messages, and keep other people's authorship intact when importing their commits.

Agents: set this before your first commit in a clone or worktree:

git config user.name  "<HUMAN NAME>"
git config user.email "<ID>+<USERNAME>@users.noreply.github.com"

Decompilation workflow tools

The standard-library Python tools below keep investigation and validation evidence outside the checkout. Use Python 3.10 or newer. Generated packets can contain original-game information: do not commit or publish them. These tools do not rename symbols, promote units to Matching, or merge changes automatically.

Validation snapshots

tools/decomp_build.py runs with nice, Ninja, DTK, and objdiff available. On Windows, use native Python and Ninja; nice can come from MSYS2. Windows uses the compiler and linker directly through sjiswrap.exe; POSIX additionally requires wibo. DTK and objdiff defaults select .exe on Windows. Keep native Git on Python's PATH so provenance commands use native Windows paths. Start with an initialized, warm checkout. Choose a fresh external output directory for every run and the same external lock path for all cooperating workers:

python3 tools/decomp_build.py baseline --mode full --jobs 4 \
  --output ../validation/baseline --lock ../validation/team.lock

The tool configures the selected version, builds, checks all 127 output hashes, and generates a report. Existing comparison objects are refreshed; absent unlinked draft objects are recorded as unavailable rather than compiled implicitly. Candidate runs can reuse the entire validated baseline report when its complete comparison configuration, object contents (including unavailable objects), and report-generation inputs are identical. This does not skip the build, output-hash checks, or source-drift checks. Changed compatible inputs regenerate the report; incompatible tools or original binaries still require a new baseline. Older evidence without a reuse key also regenerates. Use --fresh-report to force independent generation. The manifest records whether the report was generated or reused and identifies the evidence it came from. validation.json records command logs and timings, working-source/configuration/tool/artifact fingerprints, and the Git revision. The working snapshot is identified separately from its Git HEAD; it may include uncommitted files. This is a provenance record, not a content-addressed build cache. Normal Ninja dependency correctness remains required; avoid copying build caches between checkout paths. Source inputs must remain unchanged while validation runs.

Read the full revision and source fingerprint from the baseline's validation.json, then pass them explicitly when checking a candidate:

python3 tools/decomp_build.py run --mode full --jobs 4 \
  --baseline ../validation/baseline \
  --expected-baseline-revision "$BASELINE_REVISION" \
  --expected-baseline-fingerprint "$BASELINE_FINGERPRINT" \
  --output ../validation/candidate --lock ../validation/team.lock
python3 tools/decomp_build.py compare ../validation/baseline ../validation/candidate

For iteration, use --mode objects --target build/RSBE01_02/src/path/to/unit.o with a target listed in the checkout's objdiff configuration. Repeat --target for related units. A scoped check is explicitly not the full 127-output gate. Comparison uses original module/address/size identities, so a symbol rename cannot hide a lost exact function. Missing or ambiguous identities fail clearly. Jobs are limited to four; the shared lock serializes cooperating runs. It does not coordinate unrelated manual builds. Failed and interrupted runs never qualify as successful baseline evidence, and an existing lock is not removed automatically.

Evidence packets

tools/decomp_evidence.py keeps imported observations, interpretations, hypotheses, and reviews in SQLite. Supply the original binary for each imported module explicitly. For example, after setting WARIO_ORIGINAL_REL to the actual original REL path:

python3 tools/decomp_evidence.py --root . --db ../evidence/index.sqlite import \
  --version RSBE01_02 --report build/RSBE01_02/report.json --objdiff objdiff.json \
  --binary "ft_wario=$WARIO_ORIGINAL_REL" \
  --unit ft_wario/mo_fighter/ft_wario/wn_wario_bike_status_uniq_process_wheelie
python3 tools/decomp_evidence.py --root . --db ../evidence/index.sqlite packet \
  --unit ft_wario/mo_fighter/ft_wario/wn_wario_bike_status_uniq_process_wheelie --out ../evidence/packets

Packets include stable binary-hash/module/address/size function identities, reported object comparisons, source/header and symbol/split context, and hashed evidence references. Optional --assembly UNIT=FILE and --map MODULE=FILE inputs add observed direct-call operands and labels. Lexical declarations, map labels, and percentages are not semantic or ABI proof, and importing a report does not validate that report against current source.

Use claim to append an interpretation or hypothesis with a subject ID and explicit artifact IDs from a packet; use review to record a separate review. See each subcommand's --help for required arguments. Conflicting claims remain visible, and changed evidence is flagged for renewed review rather than silently replacing history. Keep generated databases and packets outside Git.

When parallel work is explicitly authorized, assign each reconstruction worker a related behavior family and exclusive source ownership. Give a separate reviewer the evidence packet and original behavior to check independently. Assign one owner for shared interfaces, freeze the combined source during validation, and publish only the exact source tree that passed. Preserve unfinished candidates separately.

Link diagnostics

Normal REL builds link the original object list directly to .plf. Preliminary -r links are independent diagnostic targets, not prerequisites for the final -r1 link. To request one explicitly:

ninja build/RSBE01_02/sora_melee/sora_melee.preplf

Read-only triage

tools/decomp_triage.py adapts ideas from KakarottoCake/decomp-triage to Brawl's MWCC GC/3.0a5.2. It provides three advisory commands:

python3 tools/decomp_triage.py queue --report ../validation/baseline/report.json \
  --claims ../evidence/claims.txt --output ../evidence/queue.json
python3 tools/decomp_triage.py frames \
  --unit wn_wario_bike_status_uniq_process_turn --output ../evidence/frames.json
python3 tools/decomp_triage.py levers --symptom stack --output ../evidence/levers.json

The queue reads configure.py without executing it, lists only NonMatching sources, and ranks fighter behavior before stage/item behavior. Missing compiled drafts remain unavailable. An external claims snapshot can flag explicit paths and module names; inspect the board as well because free-text claims may not map to files.

Frame diagnostics read original and compiled PPC ELF objects from objdiff.json. They compare relocation signatures as well as instruction bytes. Frame-only hypotheses accept only recognized stack accesses with the expected displacement change; changed literals and object fields are not excused. Relocation labels and section offsets can differ between split originals and compiled objects, so a diagnostic difference is not itself proof of an incorrect target. Use objdiff and the full validation gate for exactness and linked-output decisions.

The levers command searches TIPS.md, retaining its stated confidence and source hash. Sunshine compiler observations are not treated as proven Brawl rules. All three commands leave source, claims, and Matching status untouched; generated JSON must be outside the checkout and cannot overwrite existing evidence.

Synthetic tooling tests require no game assets:

python3 -m unittest discover -s tests -p 'test_decomp_*.py'
